The HZS75 concrete batching station is a semi-automatic complete concrete mixing equipment composed of feeding, batching, mixing, electrical control, and steel structure components. It is suitable for small-scale construction sites, precast component factories, and commercial concrete production plants. Its main features are as follows:
Modular Combined Structure: Adopts a unitized modular design, making installation and relocation extremely convenient.
High-Quality Mixing Host: The mixing main machine and aggregate hoisting system use a JS1500 twin-shaft forced concrete mixer, ensuring excellent mixing quality and high efficiency.
Precise Aggregate Batching: Equipped with a PLD2400 batching machine for accurate aggregate metering and high production efficiency.
Accurate Powder Measurement: Uses electronic scales for powder metering, achieving high batching precision.
Simple and Practical Water Measurement: Employs flow metering for water, which is both simple and practical while ensuring high batching accuracy.
Concrete Batching Plant HZS60 | Unit | Parameter |
Maximum Theoretical Production Rate | m3/h | 75 |
Main Unit Nominal Capacity | m3 | 1.5 |
Aggregate Weigher Maximum Weighing Capacity | kg | 2400 |
Cement Batch Weigher Limit | kg | 900 |
Water Weigher Maximum Weighing Capacity | kg | 400 |
Maximum Weighing Value of Admixtures | kg | 50 |
| Cement Silo Capacity | t | 100
|
Mixing Power (JS1500) | kW | 30×2 |
Hoisting Power | kW | 18.5 |
Total Installed Power | kW | 90 |
Discharge Height | m | 4.2m |
Aggregate Weighing Accuracy | % | ±2 |
Water Metering Accuracy | % | ±1 |
| Cement Weighing Accuracy | % | ±1 |
Admixture Dosing Accuracy | % | ±1 |
Automatic Cycle Time | S | 72 |
Concrete Batching Plant HZS75-1Q1500.pdf
