1. Rapid Installation
The HZS60 concrete batching station adopts a steel beam installation method. The main system can be unloaded and installed within just a few hours, and the complete installation including the control room, batching station, and other supporting facilities can be completed in 2-4 days, making it ready for production.
2. Reasonable Design
The mixing platform, metering platform, and hoisting system platform of the HZS60 are designed with high rationality, fully ensuring convenient inspection and maintenance of equipment.
Even when installing external protective layers, sufficient space for daily operations is still guaranteed.
3. Small Footprint
The HZS60 uses a belt-type or bucket elevator feeding method. The design of the belt and hopper enables high-efficiency loading and dumping of aggregates, significantly reducing the occupied site area.
4. Low Investment and Simple Maintenance
-
The HZS60 requires low capital investment, occupies a small site area, and uses minimal auxiliary equipment.
It features simple equipment maintenance and safe, convenient operation.
Concrete Batching Plant HZS60 | Unit | Parameter |
Maximum Theoretical Production Rate | m3/h | 60 |
Main Unit Nominal Capacity | m3 | 1.0 |
Aggregate Weigher Maximum Weighing Capacity | kg | 1600 |
Cement Batch Weigher Limit | kg | 400 |
Water Weigher Maximum Weighing Capacity | kg | 300 |
Maximum Weighing Value of Admixtures | kg | 50 |
| Cement Silo Capacity | t | 100
|
Mixing Power (JS1000) | kW | 18.5×2 |
Hoisting Power | kW | 11 |
Total Installed Power | kW | 80 |
Discharge Height | m | 4.1m |
Aggregate Weighing Accuracy | % | ±2 |
Water Metering Accuracy | % | ±1 |
| Cement Weighing Accuracy | % | ±1 |
Admixture Dosing Accuracy | % | ±1 |
Automatic Cycle Time | S | 60 |
Concrete Batching Plant HZS60-1Q1000.pdf
